Please handle with care to avoid bumping to affect the linear accuracy of the guide pair. It is not allowed to remove the slide from the guide rail or push it back beyond the stroke. If the installation is difficult and the slide needs to be removed, you can order the guide rail from our company.

（引導軌是一種裝配輔助工具，其實際尺寸比導軌小一號。需要時，可將導軌與引導軌的端頭對接，把滑塊從導軌推到引導軌上，當導軌安裝好后，再將滑塊從引導軌上推到導軌上，注意基準方向）。

(the guide rail is an assembly aid whose actual size is one size smaller than the guide rail. If necessary, butt the end of the guide rail with the guide rail, and push the slider from the guide rail to the guide rail. When the guide rail is installed, push the slider from the guide rail to the guide rail, and pay attention to the reference direction).

線性導軌潤滑

Linear guide lubrication

線性導軌副的的潤滑的主要目的是減少摩擦和磨損以防止過熱，破壞其內部結構，影響導軌副的運動功能。線性導軌副在出廠之前均已經填注了低噪音潤滑脂，以保證滾珠在運行過程的良好潤滑。

The main purpose of lubrication of linear guide pair is to reduce friction and wear to prevent overheating, damage its internal structure and affect the motion function of guide pair. The linear guide pair has been filled with low-noise high-grade grease before leaving the factory to ensure the good lubrication of the ball during operation.

但為了避免因潤滑損耗造成的潤滑損耗造成的潤滑不足，建議在滑塊實際總運動行行程50km時候定期補充。當線性滑軌副的運動速度為高速時（V≥35m/min），使用N32潤滑或接油管強制潤滑。低速時（V≤35m/min）使用鋰基潤滑脂潤滑。

However, in order to avoid insufficient lubrication caused by lubrication loss, it is recommended to supplement the slider regularly when the actual total travel distance is 50km. When the velocity of linear slide pair is high speed (V ≥ 35m / min), N32 lubrication or tubing forced lubrication is recommended. Lithium grease is recommended for low speed (V ≤ 35m / min).
