直線導軌運用常見問題匯總
來源:http://www.idczc.com/ 日期:2023-01-31 發布人:
伴隨著精密傳動配件直線導軌在自動化技能行業的發展趨勢,掌握一些直線導軌常見疑難問題是非常重要的,掌握越多有關直線導軌的知識,有益于我們在應對直線導軌,碰到難題時能得到及時、有效的處理,以便更好的使用直線導軌。下面導軌絲杠廠家來為您講解下直線導軌運用常見問題匯總。
With the development trend of linear guide rail of precision transmission accessories in the automation technology industry, it is very important to master some common difficult problems of linear guide rail. Mastering more professional knowledge about linear guide rail will help us deal with linear guide rail in a timely and effective manner when we encounter problems, so as to better use linear guide rail. The guide rail lead screw manufacturer will explain to you the summary of common problems in the use of linear guide rail.
直線導軌運用常見問題點:
Common problems in the application of linear guide rail:
1、運作一段時間之后,可能會發現直線導軌的軌跡有印壓痕,而且滑塊鋼珠開裂,這是什么原因?
1. After operating for a period of time, it may be found that the track of the linear guide rail has imprints, and the slide steel ball is cracked. What is the reason?
一般是因為負荷過大,鋼珠離開軌跡,造成鋼珠開裂導致軌跡持續損害。這種情況可以考慮拆換大一級的滑塊,比如20的,更換成25的,或者增加滑塊數量,降低外部荷載,改變安裝辦法下降一側承受能力情況。倘若來源于光滑的原因,可以考慮選用另一種潤滑油,增加潤滑度,減小潤化間距。必須經常查看有沒有臟東西進到滑軌,若有臟東西進入就需要改進密封性零配件,或者增加防塵配件。
It is generally because the load is too large and the steel ball leaves the track, causing the steel ball to crack and cause continuous damage to the track. In this case, it can be considered to replace the sliders of a higher level, such as 20 and 25, or increase the number of sliders, reduce the external load, and change the installation method to reduce the bearing capacity of one side. If it comes from the reason of smoothness, another lubricating oil can be considered to increase the degree of lubrication and reduce the wetting distance. It is necessary to check whether there is dirt entering the slide rail. If there is dirt entering, it is necessary to improve the sealing parts or add dust-proof parts.


2、滑塊運作一段時間后會出現鋼珠掉出來的情況是為什么?
2. Why does the steel ball fall out after the slider operates for a period of time?
鐵銷從珠溝掉下來導致鋼珠損害使用期結束,使鋼件表面有疲倦與負荷過重的情況,或許是由于太多負荷、安裝不正確或只要一側承受力距,這些情況,都有或許導致鋼珠脫落。
The iron pin fell from the bead groove, resulting in the end of the service life of the steel ball damage, fatigue and excessive load on the surface of the steel parts, which may be due to too much load, incorrect installation or as long as one side bears the force distance, all of which may cause the steel ball to fall off.
3、在滑塊行走一段時間后,發現軸承端蓋與端防污有形變或裂開情況?
3. After the sliding block has been running for a period of time, it is found that the bearing end cover and end anti-fouling are deformed or cracked?
安裝辦法的有誤,會讓滑塊與軌道間僅有一側承受力,也或許是遭到外力損害而導致軸承端蓋與端防污的形變或裂開。滑塊內部較差的,能夠變化防污體系,更換別的光滑油脂,加上光滑油量,下降潤化時間距離。安裝時要注意安裝視角的難點,產品裝備的提升,需要由的技能工程師來安裝,防止損害直線導軌滑塊。
If the installation method is incorrect, only one side between the slide block and the rail will bear the force, or the bearing end cover and end anti-fouling will be deformed or cracked due to external force damage. If the inside of the slider is poor, it can change the antifouling system, replace other smooth grease, add the amount of smooth oil, and reduce the wetting time distance. During installation, pay attention to the difficulty of installation perspective. The improvement of product equipment needs to be installed by professional skilled engineers to prevent damage to the linear guide slide.
以上關于直線導軌使用常見問題點反饋匯總,僅僅日常工作中遇到的常見的一部分問題,歡迎朋友們補充,也可聯系我們http://www.idczc.com!
The above feedback summary of common problems in the use of linear guide rail is only a part of common problems encountered in daily work. Friends are welcome to add or contact us http://www.idczc.com !
