在機械傳動領域，絲杠作為將旋轉運動轉化為直線運動的核心元件，堪稱現代工業的“關節”。從數控機床到機器人關節，從航空航天到精密儀器，絲杠的性能直接影響著設備的精度與壽命。本文將深入解析絲杠的分類體系與結構特征，揭開這一精密傳動元件的機械密碼。

　　In the field of mechanical transmission, the screw, as the core component that converts rotational motion into linear motion, can be regarded as the "joint" of modern industry. From CNC machine tools to robot joints, from aerospace to precision instruments, the performance of lead screws directly affects the accuracy and lifespan of equipment. This article will delve into the classification system and structural characteristics of lead screws, uncovering the mechanical code of this precision transmission component.

　　滑動絲杠：機械傳動的原始基因

　　Sliding screw: the original gene of mechanical transmission

　　滑動絲杠作為傳統的傳動形式，其結構可追溯阿基米德螺旋原理。這類絲杠由絲桿與螺母組成，通過螺紋副的直接接觸實現傳動。其結構特點呈現出鮮明的原始機械美學：

　　The sliding screw, as the most traditional form of transmission, can be traced back to the Archimedes screw principle in terms of its structure. This type of screw is composed of a threaded rod and a nut, and transmission is achieved through direct contact of the threaded pair. Its structural characteristics present a distinct primitive mechanical aesthetics:

　　螺紋形制：多采用梯形或鋸齒形螺紋，梯形螺紋因工藝成熟成為通用標準，鋸齒形螺紋則通過單側受力設計提升傳動效率。

　　Thread form: Trapezoidal or serrated threads are commonly used. Trapezoidal threads have become a universal standard due to mature technology, while serrated threads improve transmission efficiency through single-sided force design.

　　潤滑系統：依賴油脂或油膜潤滑，螺紋表面常加工儲油槽，形成動壓潤滑膜以降低摩擦系數。某型滑動絲杠通過激光微織構技術在螺紋表面加工出微型儲油坑，使?jié)櫥芴嵘?0%。

　　Lubrication system: relying on grease or oil film lubrication, the threaded surface is often machined with oil storage tanks to form a dynamic pressure lubrication film to reduce the friction coefficient. A certain type of sliding screw uses laser micro texturing technology to create micro oil storage pits on the surface of the thread, which increases lubrication efficiency by 40%.

　　精度等級：受材料變形與磨損限制，通常分為C0-C7七個精度等級，C3級已可滿足普通機床進給需求。

　　Accuracy level: Due to material deformation and wear limitations, it is usually divided into seven accuracy levels C0-C7, and C3 level can already meet the feed requirements of ordinary machine tools.

　　滾珠絲杠：滾動傳動的效率革命

　　Ball screw: an efficiency revolution in rolling transmission

　　滾珠絲杠通過引入滾動體，將滑動摩擦轉化為滾動摩擦，堪稱傳動效率的革命性突破。其結構特征彰顯現代精密制造技術：

　　The ball screw transforms sliding friction into rolling friction by introducing rolling elements, which can be regarded as a revolutionary breakthrough in transmission efficiency. Its structural features highlight modern precision manufacturing technology:

　　循環系統：采用回珠器構建滾珠循環通道，內循環式通過反向器實現滾珠閉環，外循環式則利用導管形成開放回路。某企業研發的S形反向器，使?jié)L珠運行流暢度提升35%。

　　Circulating system: A ball return device is used to construct a ball circulation channel. The internal circulation type uses a reversing device to achieve ball closure, while the external circulation type uses a conduit to form an open circuit. The S-shaped reverser developed by a certain enterprise has improved the smoothness of ball operation by 35%.

　　預緊機制：通過雙螺母墊片式或變位導程式預緊，軸向間隙。某精密滾珠絲杠采用齒差式預緊結構，可實現1μm級重復定位精度。

　　Pre tightening mechanism: eliminate axial clearance by pre tightening with double nut washers or displacement guides. A certain precision ball screw adopts a tooth difference pre tightening structure, which can achieve a repeat positioning accuracy of 1 μ m.

　　密封防護：多重密封結構成為標配，迷宮式密封配合唇形密封圈，有效阻隔切削液與粉塵侵入。某款防塵滾珠絲杠在模擬切削試驗中，實現連續工作500小時無故障。

　　Sealing protection: Multiple sealing structures have become standard, and labyrinth seals combined with lip seals effectively block the intrusion of cutting fluid and dust. A certain dust-proof ball screw achieved continuous operation for 500 hours without failure in simulated cutting tests.

　　行星滾柱絲杠：重載傳動的力量美學

　　Planetary Roller Screw: Aesthetics of Power in Heavy Duty Transmission

　　針對航空航天、工程機械等重載場景，行星滾柱絲杠通過創新結構實現大載荷傳動：

　　For heavy-duty scenarios such as aerospace and engineering machinery, planetary roller screws achieve high load transmission through innovative structures

　　多齒嚙合：絲桿與螺母間布置多個滾柱，形成多線接觸。某型產品實現同時12個滾柱參與嚙合，額定動載荷較滾珠絲杠提升3倍。

　　Multi tooth meshing: Multiple rollers are arranged between the screw and nut to form multi line contact. A certain type of product achieves simultaneous engagement of 12 rollers, with a rated dynamic load three times higher than that of ball screws.

　　齒廓修形：采用對數螺旋線齒廓，使接觸應力分布更均勻。有限元分析顯示，優化后齒面應力下降28%。

　　Tooth profile modification: using logarithmic spiral tooth profile to make the contact stress distribution more uniform. Finite element analysis shows that the maximum stress on the optimized tooth surface has decreased by 28%.

　　潤滑管理：開發固態潤滑膜技術，在滾柱表面沉積二硫化鉬涂層，形成自潤滑層，滿足極端工況需求。

　　Lubrication management: Develop solid-state lubrication film technology to deposit molybdenum disulfide coating on the surface of rollers, forming a self-lubricating layer to meet extreme working conditions.

　　靜壓絲杠：液體膜傳動的精度

　　Static pressure screw: the pinnacle of precision in liquid film transmission

　　靜壓絲杠通過液壓油膜實現純液體摩擦，代表傳動精度的境界：

　　The static pressure screw achieves pure liquid friction through hydraulic oil film, representing the highest level of transmission accuracy:

　　油腔結構：螺母內加工環形油腔，通過節流器控制油膜壓力。某研究機構開發的雙矩形油腔結構，使油膜剛度提升50%。

　　Oil chamber structure: A circular oil chamber is machined inside the nut, and the oil film pressure is controlled by a throttle. The double rectangular oil chamber structure developed by a certain research institution has increased the stiffness of the oil film by 50%.

　　供油系統：采用恒壓供油裝置，配合高精度過濾器，確保油液清潔度達NAS 5級。

　　Oil supply system: Adopting a constant pressure oil supply device, coupled with high-precision filters, to ensure that the oil cleanliness reaches NAS level 5.

　　熱管理：內置溫度傳感器與冷卻通道，通過PID算法實時調節油溫，將熱變形控制在0.01μm/℃以內。

　　Thermal management: Built in temperature sensor and cooling channel, real-time adjustment of oil temperature through PID algorithm, controlling thermal deformation within 0.01 μ m/℃.

　　絲杠的演化史，本質是機械傳動領域?qū)π?、精度與壽命的不懈追求。從滑動摩擦到滾動摩擦，從剛性接觸到液體膜傳動，每種絲杠類型都承載著特定的工程智慧。理解其分類邏輯與結構特征，不僅是對機械原理的致敬，更是掌握現代精密制造的關鍵密碼。在工業4.0時代，絲杠技術正與智能傳感、數字孿生等技術深度融合，持續拓展著機械傳動的可能性邊界。

　　The evolution history of screw is essentially the relentless pursuit of efficiency, accuracy, and lifespan in the field of mechanical transmission. From sliding friction to rolling friction, from rigid contact to liquid film transmission, each type of screw carries specific engineering wisdom. Understanding its classification logic and structural features is not only a tribute to mechanical principles, but also a key password for mastering modern precision manufacturing. In the era of Industry 4.0, screw technology is deeply integrated with intelligent sensing, digital twin and other technologies, continuously expanding the possibilities of mechanical transmission.
